One tracker for every farm vehicle.
The Cheka tracker fits trucks, trailers, tractors, bakkies and tankers. It records position and vibration. Wireless sensors add temperature and humidity from inside the load.
Specifications.
- Position
- GPS position, speed, heading and altitude
- Vibration
- Measured all the time. About 37,000 data points per minute
- Supply
- 6 to 100 V DC vehicle power
- Backup
- Internal battery. Records when vehicle power is off
- Network
- LTE Cat 1bis with GSM fallback
- Wake
- Low-power sleep. Wakes on motion
- Mount
- Four bolts on the chassis
- Updates
- Firmware and settings updated over the air
- Health
- Supply voltage, battery, signal and board temperature reported to the dashboard
Measure inside the load.
Battery-powered Bluetooth sensors go inside a trailer, a cold room or a bin. The tracker on the vehicle collects their readings and sends them with its own data.
- Temperature and humidity.
- Vibration on a sensor model with an accelerometer.
- No wiring. Move a sensor between trailers when you need to.
- The dashboard shows each sensor by name, its battery and its faults.
- Each reading keeps the sensor name, so two sensors in one trailer stay separate.
Fitted in one visit.
Mount
Bolt the tracker to the chassis. Write down the position and the direction it faces.
Connect
Connect the tracker to vehicle power, 6 to 100 V DC.
Assign
Link the tracker to the vehicle in the dashboard. Add wireless sensors to the trailer.
Check
Drive a short distance. The dashboard checks the mount orientation and shows the first trip.
When a tracker moves to another vehicle, the dashboard keeps the history. Old trips stay with the old vehicle.
